EOX Rebuild is the dedicated full replacement product from TK Elevator’s EOX family of energy efficient and natively digital lifts. It comes with all the eco-digital advantages of the EOX elevator platform, and added flexibility to efficiently adapt to existing elevator shafts. Replacing the old elevator in your building with an EOX Rebuild lift will dramatically improve safety, accessibility, ride comfort, reliability, and the overall passenger experience, while at the same time lowering energy consumption and running costs.
EOX Rebuild at a glance
| OVERVIEW | |
|---|---|
| Elevator type | Machine room-less with belt technology, made in Europe |
| Applications | Full replacement in existing residential buildings and in low-rise commercial buildings such as offices, hotels and public buildings |
| Load | 320 / 450 / 630 / 825 / 1000 kg |
| Speed | 1.0 m/s | 1.6 m/s | 1.75 m/s |
| Travel height | Up to 40 m (1.0 m/s) | Up to 75 m (>1.0 m/s) |
| Number of stops | Up to 25 stops |
| Cabin | Predesigned from design lines C, B or A incl. custom cabin option |
| Door types | Side-opening with 2 or 3 panels, central-opening with 4 panels |
| Door opening width | 700 – 1000 mm |
| Door height | 2000 / 2100 mm |
| Cabin height | 2100 / 2200 / 2300 mm |
| Flexibility | Flexible cabin dimensions in 10 mm steps |
| Flexible door positioning in 1 mm steps | |
| Energy efficiency | Regenerative drive |
| Standby-mode and eco-mode | |
| Digital components | IoT-enabled and AI-ready computing hardware |
| Smart sensors including in-cabin optical sensor | |
| Passenger experience | 7″ / 10″ in-cabin multimedia display with infotainment |
| Elevator calls with AGILE Mobile app | |
| Special options | Extra-reduced shaft head and reduced pit |
| 230V single-phase power supply | |
